Product Description
Feature:
- Binocular lens: 32:9 super-wide picture;
- Sensor: 2PCS 1/2.9″ CMOS SENSOR
- Video: H265+/H265 /H.264 compression, Dual Streaming
- Resolution: Main Stream:3840*1080(4MP);Sub-stream:1280*360
- 4MMlens horizontal viewing Angle of 170°,
- Support dual light source alarm/smart humanoid detection/sound alarm/voice intercom
Product Characteristics
Intelligent Recognition
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod.
High Definition Images
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod.
Wide Angle and Zoom Capabilities
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod.
Cloud Storage
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod.
Product Parameters
Specification | XZ-5AV-MD |
Structure | MSC30KQ + 2pcs 1/2.9″ CMOS sensor |
Binocular lens | Dual-lens picture splicing achieves ultra-wide Angle without deformation |
Audio | 1ch mic/1ch spk(8Ω2W) |
VIDEO | Support OSD,BLC,HLC,3D NR;Brightness/Contrast/Saturation/Sharpness Adjustable ;Support dual light source alarm/smart humanoid detection/sound alarm/voice intercom; |
lens | 4mm*2 |
Lens type&FOV | horizontal FOV 170°, vertical FOV 52°; |
IR Led | 3pcs IR Led,2pcs white light, IR distance 20-30M; |
frequency | 50Hz/60Hz |
Coded Format | H.264 /H265/H265+ |
Image Resolution | Main Stream:3840*1080;1-20fps |
Sub-stream:1280*360;1-20fps | |
Video Compression Rate | 512Kbps-5Mbps continuously adjustable, support CBR/VBR |
Audio Frequency Code | G.711/G.711A/AAC audio standard,Support two way audio, Support audio and video synchronization |
Network Port | 10/100M self-adapt Ethernet port, lighting protection |
Protocol | Support HTTP/RTSP/DHCP/NTP/P2P,etc; |
TF Card | Support MAX:512G |
Phone Client | Support iPhone、Android |
Business Function | support unit client software,support CMS platform system application. |
Feature | support day/night(support IR-CUT),support LDR signal linkage |
Operating temperature | -20~60° |
General Parameters | DC12V |
Device Size | 200*110*75mm |
You May Also Like
Product Advantages
years experience in CCTV industry, has our own R&D team for hardware and software, Non-dust workshop, strict QC process, aging-test, good after-sale services and technical support. At our here , for the products, that we not only have front end camera equipment , but also have back end storage NVRs, DVRs equipment; So , for us , to providing the whole CCTV system to our customers all are safe : include the hard firmware &software, If you choose us to cooperation, the money also is safe!
